No. | Itme No. | Description | Capacity (based on density 0.6/m3) | Thickness of upper T Cone (mm) | Thickness of corrugated plate (mm) | Rings of corrugated plate | ||||||
upper | middle | lower | Rings | Details | ||||||||
1 | 60010001 | silos 2.7m3/Φ1530 | about 1.7T | 1.0 | 1.2 | 1 | 2 | |||||
2 | 60010002 | silos 4.1m3/Φ1530 | about 2.7T | 1.0 | 1.0 | 1.2 | 2 | upper2+lower2 | ||||
3 | 60010003 | silos 6.4m3/Φ2140 | about 3.6T | 1.0 | 1.2 | 1 | 2 | |||||
4 | 60010004 | silos 9.3m3/Φ2140 | about 5.4T | 1.0 | 1.0 | 1.2 | 2 | upper2+lower2 | ||||
5 | 60010005 | silos 12.2m3/Φ2140 | about 7.3T | 1.0 | 1.0 | 1.0 | 1.2 | 3 | upper2+middle2+lower2 | |||
6 | 60010006 | silos 15.8m3/Φ2750 | about 10.5T | 1.2 | 1.0 | 1.2 | 2 | upper3+lower3 | ||||
7 | 60010007 | silos 20.6m3/Φ2750 | about 13.8T | 1.2 | 1.0 | 1.2 | 1.2 | 3 | upper3+middle3+lower3 | |||
8 | 60010008 | silos 25.5m3/Φ2750 | about 17.1T | 1.2 | 1.0 | 1.2 | 1.2 | 4 | upper3+middle6+lower3 | |||
9 | 60010009 | silos 32.1m3/Φ3669 | about 22T | 1.5 | 1.2 | 1.2 | 2 | upper4+lower4 | ||||
10 | 60010010 | silos 40.6m3/Φ3669 | about 27T | 1.5 | 1.2 | 1.2 | 1.2 | 3 | upper4+middle4+lower4 | |||
11 | 60010011 | silos 49.1m3/Φ3669 | about 32T | 1.5 | 1.2 | 1.2 | 1.2 | 4 | upper4+middle8+lower4 | |||
No. | Itme No. | Thickness of lower T Cone (mm) | Thickness of the leg（mm） | Number of legs | Weight （kg） | Maximum Height （mm） |
1 | 60010001 | 1.0 | 2.0 | 4 | 238 | 3800 |
2 | 60010002 | 1.0 | 2.0 | 4 | 282 | 4616 |
3 | 60010003 | 1.2 | 2.5 | 4 | 370 | 4705 |
4 | 60010004 | 1.2 | 2.5 | 4 | 434 | 5521 |
5 | 60010005 | 1.2 | 2.5 | 4 | 495 | 6337 |
6 | 60010006 | 1.2 | 2.5 | 6 | 637 | 5716 |
7 | 60010007 | 1.2 | 2.5 | 6 | 730 | 6532 |
8 | 60010008 | 1.2 | 2.5 | 6 | 820 | 7348 |
9 | 60010009 | 1.5 | 2.5 | 8 | 1082 | 6780 |
10 | 60010010 | 1.5 | 2.5 | 8 | 1221 | 7596 |
11 | 60010011 | 1.5 | 2.5 | 8 | 1360 | 8412 |
No. | Itme No. | Description | Material tower weight (kg) | Pallet model | Pallet weight (kg) | Cubic / pallet | Column length/m | Pallet specification (m) |
1 | 60010001 | Material tower 2.7m3/Φ1530 （1.7T） | 282 | φ1530 | 9.6 (within 2 sets) | 3 | 3 | 1.7*1.0 |
2 | 60010002 | Material tower 4.1m3/Φ1530 （2.7T) | 330 | 17.8 (more than 2 sets and less than or equal to 4 sets) | ||||
3 | 60010003 | Material tower 6.4m3/Φ2140 (3.6T) | 375 | φ2140 | 18.5 (within 2 sets) 36 (more than 2 sets and less than or equal to 5 sets) | 4 | 3.7 | 2.35*1.15 |
4 | 60010004 | Material tower 9.3m3/Φ2140 (5.4T) | 441 | |||||
5 | 60010005 | Material tower 12.2m3/Φ2140 (7.3T) | 510 | |||||
6 | 60010006 | Material tower 15.8m3/Φ2750 (10.5T) | 600 | φ2750 | 21.6 (within 2 sets) 39.9 (more than 2 sets and less than or equal to 5 sets) | 5.5 | 3.708 | 2.54*1.48 |
7 | 60010007 | Material tower 20.6m3/Φ2750 (13.8T) | 730 | |||||
8 | 60010008 | Material tower 25.5m3/Φ2750 (17.1T） | 820 | |||||
9 | 60010009 | Material tower 32.1m3/Φ3669 （22T） | 1100 | φ3669 | 48.2 | 7 | 3.5*1.5 | |
10 | 60010010 | Material tower 40.6m3/Φ3669 （27T） | 1221 | |||||
11 | 60010011 | Material tower 49.1m3/Φ3669 （32T） | 1310 |
